RUNPOWER PLC programmable logic controllers RPC3000
Elevate your industrial automation capabilities with Runpower's RPC3000 PLC control system. Specifically designed for medium to large-scale projects, RPC3000 sets new standards in sophistication, stability, openness, and user-friendliness. Its modular design facilitates easy installation, while the integration of the latest Codesys software ensures intuitive and user-friendly programming. With versatile communication ports, RPC3000 seamlessly connects with 3rd party equipment and systems, providing adaptability for evolving industrial needs. Unleash the power of advanced control technology with RPC3000, where innovation meets reliability.
PLC Panel RPC3000
RPC3000 plc control panel is a generally a plc cabinet developed for medium and large engineering projects, it supports hot-standby, and redundancy on CPU, power supply, and network, fully integrates the advantages of PLC and DCS, and combines the application requirements of factory automation and process automation.
Excellent CPU Performance
RPC3000 series PLC CPU module core frequency up to 1GHz, very powerful performance. Fanless design, instruction speed of up to 0.01us, and a maximum of 64MB of data storage space and 16MB of program storage space, the built-in lithium-ion battery can support power down to keep 36 months, the SD card has a variety of functions such as storing data, updating the underlying program, etc. The CPU module body comes with 2 independent 100 megabit / Gigabit adaptive Ethernet ports, up to 2 independent RS485, which can be used as a master or slave. Both can be used as master or slave. A single CPU can control 4000 points of switching quantity or 2500 points of analog quantity in real-time and can collect nearly 40,000 points of switching quantity in remote IO mode.
I/O Modules of High Precision and Quality
With more than 20 years of signal acquisition design experience and the latest RPC3000PLC series IO uses high-grade components, the analog acquisition is a fully isolated design, with high precision, good stability, and communication also has a special solution. The system's immunity to interference reaches a high level. In addition to electromagnetic interference, another part of the complex environment at the site comes from excessive humidity and out-of-range temperatures and vibrations. We solve these problems through a large number of field application experience and reasonable structural design so that the reliability is the best, RPC3000 series PLC also has a good performance in high and low-temperature performance.
PLC Communication
The RPC3000 series PLC can not only be used in newly constructed projects/systems but also can be extended in existing projects/systems by supporting third-party communication protocols. At present, the communication protocols of the third-party system are supported by Profinet, EtherCAT, Modbus, and other protocols, and these communication modules can join the IO of RPC3000 series PLC as a sub-station of the original system, and the addition and writing of the program can be completed in the original programming software, reducing the workload of reprogramming. In the future, we will expand the variety of third-party communication protocols. RPC3000 series PLC communication, support, and a variety of upper unit configuration software in the foreseeable future, more and more of the configuration software will have RPC3000 series PLC and touch screen standard drive, allowing the user to be more easily configured.
PLC Connections
System communication is divided into four different types of buses: CE bus, CH bus, CC bus, and CR bus, CC bus is used for simple single IO expansion, the CH bus is responsible for redundant data synchronization and communication expansion, the CE bus is responsible for high-speed IO expansion, CR bus is responsible for networking communication of different series of products. CE double-ring redundancy may correspond to scenarios that require better control reliability, CE multi-master corresponding scenarios require control timeliness (3ms), CR network and CC network composition corresponding to low-cost and TCP/IP device compatibility, as well as Modbus corresponding remote wireless network.
CPU Modules
RPC3100SP
RPC3101
RPC3105
​
RPC3111
​
Main frequency: 168MHZ, 256K program space, 58K data space, one Ethernet port (10M/100M), three serial ports (RS485), do not support extension rack
Main frequency 600MHZ, 4M program space, 8M data space, 1 Ethernet port (10M/100M), 2 serial ports (RS485), support CC, CR bus
800MHZ main frequency, 8M program space, 32M data space, two independent Ethernet ports (10M/100M), two serial ports (RS485), support CC, CR, CH, CE bus, support software redundancy
Main frequency 1GHZ, 16M program space, 64M data space, 2 independent Ethernet ports (10M/100M), 2 serial ports (RS485), support CC, CR, CH, CE bus, support hardware redundancy
Digital I/O Modules
RPC3211
RPC3212
RPC3214
RPC3221
​
RPC3222
​
*RPC3216
*RPC3218
RPC3224
16 DC24V digital input, drain/source type
32 DC24V digital inputs, drain/source type
8 channel digital input, AC220V, single channel isolation
16 channel transistor digital output, source type, single channel maximum load capacity 500mA
32 channel transistor digital output, leakage type, single channel maximum load capacity 500mA
1 channel SSI/ incremental encoder input, 2 relay outputs
DI 8×DC24V, DO 8×DC24V transistors
DI 8×DC24V, DO 8× relay
Analog I/O Modules
RPC3310
RPC3311
RPC3312
RPC3313
RPC3320
RPC3321
8-channel analog input, current/voltage type (4 ~ 20mA/0 ~ 20mA/0 ~ 10V optional, 16-bit A/D, accuracy 0.2%, differential input, 8-channel refresh time 10ms)
8-channel thermocouple input (J, K, E, N, T, B, R, S type, accuracy 0.2%, 8-channel refresh time 20ms)
6 channel thermal resistance input (Cu50, PT100, accuracy 0.2%, 6-channel refresh time 20ms)
16 channel analog input, current type (4 ~ 20mA/0 ~ 20mA optional, 16-bit A/D, accuracy 0.5%, single-ended input, 16-channel refresh time 20ms)
4 channel analog output, current type/voltage type (0 ~ 20mA/0 ~ 10V optional, accuracy 0.5%)
8 channel analog output, current type/voltage type (0 ~ 20mA/0 ~ 10V optional, accuracy 0.5%)
Communication Modules
RPC3700
RPC3701-M
RPC3701-S
RPC3703
RPC3704
RPC3705
RPC3706
RPC3707
RPC3708
​
​
​
​
RPC3720
RPC3770
CR2000
​
CC bus local rack expansion module
CE bus remote rack extension master module
CE bus remote rack extension slave station module
Profinet communication slave station
EtherCAT communication slave station
Ehernet/IP communication slave station
CANopen communication single master station module
CAN2.0 communication, single free port module
A communication expansion module containing three serial ports (RS485) and one Ethernet (10M/100M). This module supports a maximum of six simultaneous expansion modules on the host rack and two simultaneous expansion modules on the same expansion rack. The CPU supporting the host rack must support the CH bus, and the remote rack must be configured on the CE bus rack
Redundant synchronization module with 0.5 m SPF interface optical fiber
CR bus remote communication slave module
CR bus remote communication slave station module, body with DI 10xDC24V, DO 6x relay, non-programmable, support expansion RPC2000 extension module
Rack and Power Supply
RACK004
RACK006
RACK008
RACK011
RACK015
RPC3910
RPC3921
4-slot rack
6-slot rack
8-slot rack
11-slot rack
15-slot rack
30W power supply, AC220V input
30W power supply, DC24V input
Accessories
RPB000
slot cover
Programming Software
PLC Programming Software - Codesys
CODESYS is a widely used programming software for the development and programming of PLC programmable logic controller and other industrial automation devices. It is a highly regarded software platform that serves as an exceptional programming tool for various machine and process applications, specifically designed to meet the needs of machine building and system integration industries. The codesys provides a comprehensive environment for creating control applications, offering a variety of programming languages like ladder logic, structured text, function block diagram, and more.
Resources
Our organization provides a wide array of valuable resources and PLC tools to support your needs.
Industries Served
RUNPOWER PLC has been applied in a wide range of industries and automation processes, including those mentioned above such as coal mining, public railway automation, metal processing, water treatment, Heating, ventilation and air conditioning (HVAC) industry, heating industry, transformer substations, smart factories, and so on.
PLC Testing Kits
BUY our PLC to get Codesys software for free!
1
Basic Testing kit
PLC model: RPC2000
PLC type: Micro PLC
PLC module: RPC2107N*1, RPC000*1
Power supply: 24VDC or 220VAC
I/O: 10*DI(DC24V)，6*DO(relays)
Communication ports: 1*RS232，2*RS485(isolation)，1*Ethernet
PLC protocols: MODBUS TCP, MODBUS RTU
Program download ports: Ethernet
Programming cable: 2m Ethernet cable*1
Codesys soft plc
​
​
2
Advanced Testing Kit
PLC model: RPC2000
PLC type: Micro PLC
PLC module: RPC2107N*1, RPC2330*1, RPC000*1
Power supply: 24VDC or 220VAC
I/O: 10*DI(DC24V)，6*DO(relays), 4*AI, 1*AO
Communication ports: 1*RS232，2*RS485(isolation)，1*Ethernet
PLC protocols: MODBUS TCP, MODBUS RTU
Program download ports: Ethernet
Programming cable: 2m Ethernet cable*1
Codesys soft plc
3
Redundant Testing Kit
PLC model: RPC3000
PLC type: Redundant PLC
PLC module: RACK008*1, RPC3921（24v power supply)*1, RPC3101（CPU)*1，RPC3310（8xAI)，RPC3320（4xAO)，RPC3211（16xDI 24VDC)，RPC3221（16xDO transistor)
Power supply: 24VDC or 220VAC
I/O: 16*DI, 16*DO, 8*AI, 4*AO
PLC Protocols: MODBUS TCP, MODBUS RTU
Program download port: Ethernet
Programming cable: 2m Ethernet cable*1
Codesys soft plc
